Sampat Ceramics Pvt. Ltd
17.5 KV Transformer Bushings for Voltage Class

17.5 KV Transformer Bushings for Voltage Class

300 INR/Piece

Product Details:

  • Product Type Other
  • Material Mild Steel
  • Frequency (MHz) 50 Hertz (HZ)
  • Usage Industrial
  • Click to View more
X

17.5 KV Transformer Bushings for Voltage Class Price And Quantity

  • 1 Piece
  • 300 INR/Piece

17.5 KV Transformer Bushings for Voltage Class Product Specifications

  • Other
  • Mild Steel
  • Industrial
  • 50 Hertz (HZ)

17.5 KV Transformer Bushings for Voltage Class Trade Information

  • KOLKATA
  • Cheque
  • 200 Piece Per Week
  • 1-5 Days
  • Sample costs shipping and taxes has to be paid by the buyer
  • STANDARD CRATE PACKING
  • All India

Product Description

Bu from us premium grade 17.5 KV Transformer Bushings for Voltage Class which is designed and developed for heavy duty electrical systems such as power distributions for the safe installation of conductors and also helps to prevent the flashover in case of high voltage connection contact with the transformers body. The central core of 17.5 KV Transformer Bushings for Voltage Class is made up of conducting material which is surrounded with a porcelain coating for the isolation of current carrying materials.

Transformer Bushings for Voltage Class 12, 17.5 KV

STANDARD PARTICULARS

Product no.

SC/11/0006

SC/11/0007

SC/11/0008

SC/11/0009

Bushing Rating

KV/AMP

12,17.5kv/250 Amp

12,17.5kv/400-630 Amp

12,17.5kv/1000 Amp

12,17.5kv/2000-3150Amp

Dimensions

Dia.A


135

145

165

190


Dia.B

mm

140

150

170

190


Dia.C max.

mm

111

128

163

183


Dia.D max.

mm

74

88

108

131


Dia.E min.

mm

32

39

58

74


Dia.F

mm

70

70

100

125


Dia.G

mm

15 1

24.5 5

32

50


S

mm

-

-

12

17


T

mm

22-1

30.5-5

46-2

62-2

Visible Discharge voltage

12

12

12

12

Power Frequency

Dry

38

38

38

38

One minute withstand voltage

Wet

38

38

38

38

Impulse withstand voltage

95

95

95

95

Creepage Distance (min)

mm

280

280

280

280
