Transformer Bushings of Voltage Class 36 KV

Transformer Bushings of Voltage Class 36 KV

Product Details:

X

Product Description

We are dealing in manufacturing, supplying and exporting of highly durable and long lasting Transformer Bushings of Voltage Class 36 KV which is designed for to pass an electrical conductor through grounded conducting barriers with higher safety. It is capable to withstand large current values up to 2500 ampere and an impulse withstand voltage of 170 peak kilo volt. Buy from us this top quality Transformer Bushings of Voltage Class 36 KV in large quantities in different sizes with diameter up to 100 millimeters.

Transformer Bushings of Voltage Class 36 KV

STANDARD PARTICULARS

PRODUCT NO.

SC/36/0026

SC/36/0027

SC/36/0028

SC/36/0029

Bushing Rating

KV/AMP.

36kv/ 2500 Amp.

36kv/400-630 Amp.

36kv/ 1000 Amp.

36kv/2000-3150Amp.

Dimensions

A

mm

42

50

80

100


Dia. B

mm

195

205

225

225


Dia. C

mm

200

208

230

260


Dia. D Max.

mm

111

128

163

183


Dia. E Max.

mm

74

88

108

131


Dia.F Min.

mm

33

39

58

74


Dia. G

mm

70

85

100

125


I

mm

15

24.5

32

51


J

mm

22

30.5

46

62


S

mm

-

-

12

17

Visible Discharge voltage

36

36

36

36

Power Frequency

Dry

70

70

70

70

One minute withstand voltage

Wet

KV

70

70

70

70

Impulse withstand voltage

170

170

170

170

Creepage Distance (min)

mm

900

900

900

900
